Description
Features:
- Lock nut provides positive and safe mechanical load holding
- Low friction locking rings spin easy, save time and effort
- Designed to withstand 10% side-load up to 90% of maximum stroke
- Hardened surface resists side-loading and cyclic wear
- Overflow port as stroke limiter to prevent plunger blow-out
- Weather protected, inside and out
- Replaceable bearings enclose the plunger for support throughout the stroke
- Certified lifting eyes and base mounting holes
Specifications:
- Maximum Operating Pressure (bar) : 700
- Capacity Class (tonnage) : 50
- Maximum Cylinder Capacity Advance (kN) : 550
- Stroke (mm) : 50
- Collapsed Height A (mm) : 164
- Extended Height B (mm) : 214
- Return Type : Single-Acting, Load Return
- Plunger Type : Solid
- Material : Steel
- Cylinder Effective Area Advance (cm2) : 78,5
- Oil Capacity Advance (cm3) : 393
- Sideload Resistance of Maximum Capacity (percentage) : 10%
- Surface Treatment : Nitride
- Coupler : CR400 Coupler
- Weight (kg) : 17
Dimensios:
- Collapsed Height A (mm) : 164
- Collapsed Height With Optional Tilt Saddle A1 (mm) : 179
- Optional Tilt Saddle Addition To Collapsed Height A1 (mm) : 15
- Extended Height B (mm) : 214
- Outside Diameter D (mm) : 130
- Cylinder Bore Diameter E (mm) : 100
- Plunger Diameter F (mm) : Tr 100 x 4
- Base to Advance Port H (mm) : 24
- Saddle Diameter J (mm) : 71
- Saddle Protrusion from Plunger K1 (mm) : 2
- Saddle Maximum Tilt Angle Radius (degrees) : 5
- Lock Nut Height S (mm) : 25
- Base Mounting Holes Bolt Circle U (mm) :105
- Base Mounting Holes Thread V : M8 x 1,25
- Base Mounting Holes Thread Depth Z (mm) :10
