Description
Technical data
| Range | Domain |
| Type of product or equipment | miniature circuit breaker |
| Name of the device | Domain MCB |
| Device function | Distribution |
| Description of the poles | 2P |
| number of poles protected | 2 |
| Position of the neutral pole | Left |
| In rated operational current | 16A |
| Network type | THAT |
| Trigger Type | Thermal-magnetic |
| trigger curve | VS |
| breaking capacity | Icn 3000A |
| Network frequency | 50/60Hz |
| [Ue] rated operational voltage | 230V AC 50/60Hz |
| magnetic trip limit | 510 x In |
| [Ics] rated service short-circuit breaking capacity | 3000 kA 100 % Icn conforming to EN/IEC 60898-1 |
| Fully apparent cut | Yes |
| Order type | By crankpin |
| Voltage indication | Trigger error |
| Installation mode | snap-on |
| mounting bracket | DIN rail |
| compatibility of distributors, combs, busbars | Yes |
| 9mm pitch | 4 |
| Height | 81mm |
| Lenght | 36mm |
| Depth | 78.5mm |
| Product weight | 0.19kg |
| Color | White |
| Mechanical Stamina | 20000 cycles |
| connection mode | Tunnel type terminals (top or bottom) 125 mm rigid Tunnel type terminals (top or bottom) 116 mm flexible |
| Wire stripping length | 14 mm for top or bottom connection |
| Tightening torque | 2 Nm top or bottom |
| Differential protection | Without |
