Description
The Insize ISM-ZS45-P Zoom Stereo Microscope is engineered for professionals requiring detailed observation and analysis. Its advanced optical system and ergonomic design make it an essential tool across various industries.
Key Features:
- Magnification Range: Zooms continuously from 7x to 45x, accommodating diverse inspection needs.
- Binocular Head: 45-degree inclined head with interpupillary distance adjustment (5575 mm) for comfortable viewing.
- Wide-Field Eyepieces: WF10X eyepieces with a 20 mm field number provide a broad and clear view.
- Objective Lenses: Zoom objective lenses ranging from 0.7x to 4.5x for flexible magnification.
- Illumination: Adjustable LED lighting for incident and transmitted illumination, ensuring optimal visibility.
- Working Distance: Generous 95 mm working distance facilitates manipulation of specimens.
- Diopter Adjustment: 5 diopter adjustment on both eyepieces to accommodate individual vision differences.
Specifications:
| Specification | Details |
|---|---|
| Model Number | ISM-ZS45-P |
| Magnification Range | 7x45x |
| Eyepieces | WF10X (Field Number: 20 mm) |
| Objective Lenses | 0.7×4.5x |
| Interpupillary Distance | 5575 mm |
| Diopter Adjustment | 5 diopter |
| Working Distance | 95 mm |
| Illumination | LED (incident and transmitted) |
| Power Supply | AC 220V 50Hz (standard) |
| Dimensions (LWH) | 310 mm 250 mm 420 mm |
| Weight | Approximately 5 kg |
Applications:
Ideal for applications requiring detailed visual inspection, including:
- Electronics: Circuit board examination and solder joint inspection.
- Jewelry: Gemstone analysis and quality assessment.
- Biological Research: Observation of specimens and dissections.
- Industrial Inspection: Evaluation of small components and materials.
Benefits:
- Versatility: Wide magnification range suits various tasks.
- Comfort: Ergonomic design reduces strain during extended use.
- Clarity: High-quality optics deliver sharp, detailed images.
- Efficiency: Adjustable illumination enhances visibility under different conditions.
